BeatTouch™

Innovative Haptic Solution
Based on Magneto-Rheological Elastomer

CK Materials Lab empowers device manufacturers with the most innovative haptic solution in the world.
BeatTouch™ Haptic Solution, originated from a smart material called Magneto-Rheological Elastomer(MRE),
brings brand-new tactile sensations such as rhythmical tapping, rubbing and many more to the mobile and entertainment devices.

Material

MAGNETO-RHEOLOGICAL ELASTOMER

Magneto-Rheological Elastomer(MRE), a mixture of magnetic particles and elastic substances (e.g. natural or synthetic rubber), is one of the smart materials controlled by an external magnetic field generated from the induced current. It is soft and flexible when there is no magnetic field applied, but it dramatically changes its structure and brings stiffness as magnetic field is applied. The level of stiffness varies depending on the types of magnetic particles and elastic substances.

Technology

INNOVATIVE HAPTIC SOLUTION

BeatTouch™ is an innovative haptic solution based on Magneto-Rheological Elastomer(MRE). It is a patented technology which controls the activity of MRE in various structures by the magnetic field generated from the induced current, thus creates brand new tactile sensations. The key of this technology lies in the unique formulation of MRE, its structure and the current control.

Various Structures of MRE

Plate

Tunnel

Fine Protrusion

Product

INNOVATIVE HAPTIC ACTUATORS : BeatTouch™ SERIES

BeatTouch™ Haptic Actuators – BeatTouch™-S and BeatTouch™-M and BeatTouch™-C are innovative haptic components exclusively developed by CK Materials Lab. They distinguish themselves from the existing small vibrating motors in the current market by their unique base materials, structures and most importantly, the tactile senses they create. Applied in the various types of mobile and entertainment devices, BeatTouch™ Haptic Actuators bring rhythmical tapping, rubbing and many more delicate sensations for realistic and humanized haptic feedback.

BeatTouch™ S
for Hardcase Devices

Key Highlights
Rhythmical tapping
Low power consumption (70% of LRA)
Low frequency operation (1~20Hz)
Broad frequency bandwidth
Dimension
12PI x 4T
Rated Current (Max.)
60 mA
Rated Voltage
AC 2 V
Resonant Frequency
170 Hz
Vibration Power (Min.)
2.3 G
BeatTouch™ J (F1085)
for Jog Dials and Switches

Key Highlights
MRF based Rotary Haptic Actuator
Customizable Haptic Patterns
Applicable in the various industries
Dimension
10mm x 8.5mm
Weight
5.5 ± 0.5g
Supply Voltage
5.0 Vp Pulse Wave
Operating Frequency
1 ~ 200 Hz (Recommended)
Basic Torque
Max. 0.8 mN·m@ No Input
BeatTouch™ J (F6020)
for Jog Dials and Switches

Key Highlights
MRF based Rotary Haptic Actuator
Customizable Haptic Patterns
Applicable in the various industries
Dimension
60mm x 20mm
Weight
240 ± 20g
Supply Voltage
5.0 Vp Pulse Wave
Operating Frequency
1 ~ 200 Hz (Recommended)
Basic Torque
Max. 10 mN·m@ No Input
BeatTouch™ M
for Flexible Wearables

Key Highlights
Flexible & Thin
Fast response time
Convenient of change structures
High productivity
Dimension
15 x 15 x 1.8T
Rated Current (Max.)
200 mA
Rated Voltage
AC 5 V
Resonant Frequency
160 Hz
Vibration Power (Min.)
0.6 G
BeatTouch™ C
for Wearable Devices

Key Highlights
Curved & Thin
Fast response time
Strong vibration
Dimension
14 x 30 x 2.2T
Rated Current (Max.)
140 mA
Rated Voltage
AC 2 V
Resonant Frequency
170 Hz
Vibration Power (Min.)
1.5 G

Application Field

APPLICATION FIELD

The innovative haptic actuator is the world’s first newly concept parts that can be applied into various smart devices.

Jog Dials and Switches

Wearable Device

VR Accessory

Game Controller

Tablet PC
